Descripción
Key SpecificationView More
Fixed Service Ports
48 × 10/100/1000BASE-T ports
4 × 1GE/2.5GE SFP ports
4 × 1GE/2.5GE SFP ports
Management port
1 x RJ45 console port
Switching capacity
116 Gbps
Forwarding rate
87 Mpps
Capacity of MAC address table
16000
Power module
1 x fixed power module
Fan module
2 x fan module
Cooling mode
Fan cooling
Input power
Rated input voltage range: 100V AC to 240V AC, 50/60Hz
Max. input voltage range：90V AC to 264V AC, 50/60Hz
Max. input voltage range：90V AC to 264V AC, 50/60Hz
Power consumption
30W
Surge protection
10 kV
Dimensions (W x D x H)
440 mm × 220 mm × 43.5 mm (17.32 in. x 8.66 in. × 1.71 in.)
Temperature
Operating temperature: 0°C to 45°C (32°F to 113°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Warranty
3 years
