Descripción
Key SpecificationView More
Fixed Service Ports
10 × 10/100/1000BASE-T ports, ports 1 to 8 supporting PoE/PoE+
2 × 1GE/2.5GE SFP ports
2 × 1GE/2.5GE SFP ports
Management port
1 x RJ45 console port
Switching capacity
30 Gbps
Forwarding rate
22.5 Mpps
Capacity of MAC address table
16000
Power module
1 x fixed power module
Fan module
1 x fan module
Cooling mode
Fan cooling
Input power
Rated input voltage range: 100V AC to 240V AC, 50/60Hz
Max. input voltage range：90V AC to 264V AC, 50/60Hz
Max. input voltage range：90V AC to 264V AC, 50/60Hz
Power consumption
141W (PoE budget: 125W)
Surge protection
10 kV
Dimensions (W x D x H)
297 mm × 170 mm × 44.5 mm (11.69 in. x 6.69 in. × 1.75 in.)
Temperature
Operating temperature: 0°C to 45°C (32°F to 113°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Warranty
3 years
