Descripción
| Technical Data | |
|---|---|
| GENERAL | |
| Input connector | 4-pin, 3 mm pitch |
| Input voltage max | 30 VDC |
| Output connector | 4-pin, 3 mm pitch |
| Conductor cross section | Stranded, cross section 4 x 0.20 mm2 (24 AWG) |
| Cable outer diameter | 4.5 mm |
| Maximum current | 2 A |
| Weight | 47 g |
| Total Length | 1000 mm |
| Protection material | PVC 60P BLACK |
| Flammability rating | UL 94 V-2 |
